Doran DBS5500MR Baggage Scale 24x24 500 lb.

$1,665.00
Airline baggage scale system for weighing suitcases at the airport check-in. NTEP legal for trade. Features main digital display AND remote digital display and a 24" x 24" x 5.25" scale platform. 500 x 0.5 lbs. Ground Shipping Included (cont'l US)
DBS5500MR
Qty:
Share on Facebook
GROUND SHIPPING INCLUDED (cont'l US)

AIRLINE BAGGAGE SCALE WITH MAIN AND REMOTE DISPLAY

  • Heavy duty field proven design in use in thousands of airline baggage scale installations.
  • A side load and vertical load protection system utilizing rubber shock mounts, that prevents load cell sensor damage from impact and massive overloading as baggage is loaded onto the scale platform.
  • The bright red LED read-out in the panel mount displays is easy to read from any angle.
  • Easy to operate - the two controls, ZERO and UNITS are large and color coded to prevent operator error.
  • All the scale electronics are contained in the panel mount Main Display - no additional electronics control box to install inside the counter.
  • Base size of 24" x 24" x 5.25"
  • Displays in lb or kg



Doran Model DBS Airline Baggage Scale Takes Off - The complete Model DBS Baggage Scale with the Standard Recess Mount Base and the Main and Remote Displays





2 display baggage scale

DBS5500MR -- Available with TWO displays (1 main, 1 remote)


DBS Baggage Scales Specifications

  • Max Capacity: 500 lbs.
  • Resolution: 0.5 lbs
  • Power: 115 VAC (50/60HZ, 10 watts)
  • EMI/ESD Protected
  • NTEP: nmax = 5,000d
  • Controls: ZERO (ON/OFF), UNITS
  • Construction:
    Panel Mount Displays
    - Stainless Steel Face Plate

    Standard Recess Mount Base

    - Painted Mild Steel Frame
    - 304 Stainless Steel Shroud



  • Dimensions:
    Panel Mount Display Cutout Size
    6.5" x 3.3" x 1.75" Deep

    Standard Recess Mount Base
    24" x 24" x 5.25" High



Approvals

  • NTEP (National Type Evaluation Program)
    Panel Mount Display
    CC# 05-061 5000d Class III

    Standard Recess Mount Base
    CC# 05-062 5000d Class III

indicator
customer display
Close-up view of the Main Panel Mount Display
Close-up view of the Remote Panel Mount Display

DBS5500MR STANDARD BASE DESIGN - MAIN & REMOTE DISPLAY
dbs5500mr
Model
Capacity
Base Size
500 x 0.5 lbs
24" x 24" x 5.25"

Also Available
DBS5500M STANDARD BASE DESIGN - MAIN DISPLAY ONLY
dbs5500m
Model
Capacity
Base Size
500 x 0.5 lbs
24" x 24" x 5.25"
