Unbeatable
Durability
The Navigator
NVT offers a superior mechanical overload protection system that enables
the scale to safely bear loads up to four times its rated capacity. This
is a scale built to withstand serious loads but light enough to carry.
The Navigator NVT's high-strength 304-type stainless steel pan and impact-resistant
ABS plastic housing allows the Navigator to stand up to years of use.
The innovative touchless sensors minimize the need to press the keypad
with your hand, a knife or any sharp object, reducing wear and tear on
the keypad, and increasing the effective life of the scale.
|
|
|
| |
|
Unmatched
Productivity
The Navigator NVT stabilizes in less than one second to provide fast and
repeatable weighing results. This helps to improve operator efficiency
and increases productivity. For maximum portability, this lightweight
scale can be easily transported and used in any area where power outlets
aren’t readily available. An internal rechargeable lead acid battery is
included, allowing the Navigator NVT to operate up to 100 hours on a full
charge. A wave
of the hand over the touchless sensors eliminates the extra effort or
time to press the keys, which helps increase convenience and efficiency.
A bright, backlit LCD display provides optimum visibility in any lighting
condition—indoors or out with large digits and indicators to make it fast
and easy to read results.
|
|
|
| |
|
Unsurpassed
Cleanliness
Two touchless
sensors free up your hands, allowing you to focus on handling samples
and keeping the Navigator NVT free of contaminants. The polished stainless
steel pan, corrosion-free plastic housing and spill-resistant pan sub
assembly embodies a hygienic design that is easy to clean. A full-body
in-use cover is available that wraps over and around the housing and keypad
to guard against spills, dust and contamination.
|
|
|
| Model |
|
|
|
|
|
| Capacity
x Maximum Displayed Readability |
3.2
x 0.0002 lb
51 x 0.005 or 1/8 oz
1.6 x 0.0001 kg
1,600 x 0.1 g
|
6.4
x 0.0005 lb
102 x 0.01 or 1/8 oz
3.2 x 0.0002 kg
3,200 x 0.2 g
|
16
x 0.001 lb
256 x 0.02 or 1/8 oz
6.4 x 0.0005 kg
6,400 x 0.5g
|
22
x 0.002 lb
352 x 0.05 or 1/8oz
10 x 0.0005 kg
10,000 x 0.5 g
|
32
x .002 lb
515 x 0.05 or 1/8 oz
16 x 0.0001 kg
16,000 x 1 g
|
| Displayed
Resolution |
1:16,000 |
1:16,000 |
1:12,800 |
1:20,000 |
1:16,000 |
| Repeatability
/ Linearity |
0.1
g / ±0.2 g |
0.2
g / ±0.4 g |
0.5
g / ±1 g |
0.5
g / ±1 g |
1
g / ±2 g |
| Span
Calibration Mass |
2
lb / 1 kg |
5
lb / 2 kg |
10
lb / 5 kg |
10
lb / 5 kg |
20
lb / 10 kg |
| Linearity
Calibration Mass |
2,
3 lb / 1, 1.5 kg |
2,
5 lb / 2, 3 kg |
10,
15 lb / 3, 6 kg |
10,
20 lb / 5, 10 kg |
20,
30 lb / 10, 15 kg |
| Calibration |
User-selectable
external span or linearity calibration / Digital with external weight |
| Weighing
Units |
Pound,
Ounce (decimal/fractional), Pound:Ounce (decimal/fractional ounce),
Kilogram, Gram, Troy Ounce, Grain, Newton, Carat, Pennyweight, Tael
(Hong Kong, Taiwan, Singapore), Tica, Tola |
| Application
Modes |
Weighing,
Percent Weighing, Parts Counting (min APW 1d), Checkweighing, Display
Hold, Accumulation/Totalization |
| Display |
0.78
in./ 20 mm high, 6-digit, 7-segment LCD with white LED backlight |
| Checkweigh
Indicators |
Over-Accept-Under
LCD annunciators |
| Keyboard |
4
mechanical keys, raised and with tactile feedback / 2 touchless sensors |
| Leveling
Adjustment |
Front-mounted
level bubble with illumination / adjustable leveling feet with skid-resistant
rubber pads |
| Ingress
Protection |
IP43 |
| Tare
Range |
Full
capacity by subtraction |
| Stabilization
Time |
≤1
second |
| Overload
Capacity |
400%
of rated capacity |
| AC
Power |
12VDC
0.42A AC adapter (included), 100-240V 0.25A 50-60Hz |
| Battery |
Internal
rechargeable lead acid battery, 6V 1.2AH (100-hour typical operation
with 12-hour full charge cycle) |
| Power
Conservation |
User-enabled
auto power-off after 5 minutes of inactivity |
| Operating
Temperature |
50°F
to 104°F / 10°C to 40°C at 20% to 85% relative humidity,
non-condensing |
| Pan
Size |
9
in. x 6.9 in. |
| Scale
Dimensions |
9.5W
x 9.8D x 2.8H in. |
| Shipping
Dimensions |
15.2W
x 13.2D x 6.7H in. |
| Net
Weight |
4.3
lb |
| Shipping
Weight |
6.1
lb |
|
| |
ACCESSORIES
83032107 RS232 Interface Kit, Navigator series
83032108 USB Interface Kit, Navigator series
83032109 Ethernet Interface Kit, Navigator series
83032224 Carrying Case, Navigator XT |
|
| |
| |
