Model Number	V51PH3	V51PH6	V51PH15	V51PH30
Capacity x Readability	6 lb x 0.002 lb 96 oz x 0.005 oz 96 oz x 1/4 oz 6 lb 0 oz x 0.1 oz 6 lb 0 oz x 1/4 oz 3 kg x 0.0001 kg 3000 g x 0.1 g	15 lb x 0.001 lb 240 oz x 0.01 oz 240 oz x 1/4 oz 15 lb 0 oz x 0.1 oz 15 lb 0 oz x 1/4 oz 6 kg x 0.0002 kg 6000 g x 0.2 g	30 lb x 0.001 lb 480 oz x 0.02 oz 480 oz x 1/4 oz 30 lb 0 oz x 0.1 oz 30 lb 0 oz x 1/4 oz 15 kg x 0.001 kg 15000 g x 1 g	60 lb x 0.002 lb 960 oz x 0.05 oz 960 oz x 1/4 oz 60 lb 0 oz x 0.1 oz 60 lb 0 oz x 1/4 oz 30 kg x 0.001 kg 30000 g x 1 g
Model Number	V51P3	V51P6	V51P15	V51P30
Capacity x Readability	6 lb x 0.001 lb 96 oz x 0.02 oz 96 oz x 1/4 oz 6 lb 0 oz x 0.1 oz 6 lb 0 oz x 1/4 oz 3 kg x 0.0005 kg 3000 g x 0.5 g	15 lb x 0.002 lb 240 oz x 0.05 oz 240 oz x 1/4 oz 15 lb 0 oz x 0.1 oz 15 lb 0 oz x 1/4 oz 6 kg x 0.0001 kg 6000 g x 1 g	30 lb x 0.005 lb 480 oz x 0.1 oz 480 oz x 1/4 oz 30 lb 0 oz x 0.1 oz 30 lb 0 oz x 1/4 oz 15 kg x 0.002 kg 15000 g x 2 g	60 lb x 0.01 lb 960 oz x 0.2 oz 960 oz x 1/4 oz 60 lb 0 oz x 0.2 oz 60 lb 0 oz x 1/4 oz 30 kg x 0.005 kg 30000 g x 5 g
Weighing Units	pound, decimal oz, 3/4, 1/2 and 1/4 fractional ounce, gram, kilogram, combined lb:oz display (eigher decimal or fractional ounces)
Modes	Weighing, percent weighing, checkweighing
Keyboard	4 button membrane switch
Calibration	User-selectable external span or linearity calibration
Display	0.75 inch (19 mm) high, 5 digit, 7 segment backlit blue LCD display
Display Indicators	stability, center of zero, tare or net weight, battery status, checkweigh mode
Environmental Protection	IP 43
Tare Range	Full capacity by subtraction
Stabilization Time	2 seconds or less
Auto Zero Tracking	Off, 0.5, 1 or 3 divisions
Safe Overload Capacity	150% of capacity
Operating Temperature	14°F to 104°F (-10°C to 40°C) at 10% to 85% relative humidity, Non-condensing
AC Power	9 VDC, 0.5A AC wall adapter 100-120 V AC, 50/60 Hz
Battery	Internal rechargeable sealed lead-acid battery with 120 hours continuous use
Dimensions	9 x 12 x 2.8 in
Pan Size	8.2 x 8.2 inches
Scale Weight	8.8 lb

Options/Accessories
103118 ........ 80251394 .....................Hard shell carrying case for Valor 5000
