Aluminum (Equivalent to Rice Lake RL1250 & Tedea 1250) (non ntep)
|
Model
|
Part
Number
|
Description
|
| FAY-250kg |
52634-0039
|
250kg Capacity
|
| FAY-500kg |
52634-0021
|
500kg Capacity
|
| FAY-635kg |
52634-0047
|
635kg Capacity
|
| FAY-1000kg |
52634-0013
|
1000kg Capacity
|
| Rated Output: | 2.0mV/V ±1% |
| Zero Balance: | ±5% of rated output |
| Creep after 20 mintues: | 0.02% of rated output |
| Non-linearity: | 0.02% of rated output |
| Hysteresis: | 0.02% of rated output |
| Repeatability: | 0.02% of rated output |
| Temp. effect on output: | 0.002% of applied output/°C |
| Temp. effect on zero: | 0.004% of rated output/°C |
| Safe Temperature Range: | -10°C to +50°C |
| Temp Compensated: | -10°C to +50°C |
| Safe Overload: | 2 x rated capacity |
| Input Impedance: | 410Ù ±30Ù |
| Output Impedance: | 350Ù ±5Ù |
| Insulation Resistance: | >5000 megohms |
| Rated Excitation: | 10V DC/AC |
| Maximum Excitation: | 20V DC/AC |
| Cable Length: | 10 ft. |
| Max. Platform Size | 24 x 24 inch |
